V6 (6-Inch, 150mm) ISI Certified Borewell Submersible Pumpset | 3 HP to 100 HP | 100–800 LPM | Heavy-Duty Copper Motor | Stainless Steel & Cast Iron Body

Price range: ₹63,226.00 through ₹69,456.00

  • ISI Certified V6 (6-Inch, 150mm) Borewell Submersible Pumpset designed for 6-inch and larger diameter deep borewells (100–1500 feet).

  • Complete pumpset (pump + submersible motor) solution for reliable water lifting.

  • Available from 3 HP to 100 HP for small, medium, and heavy-duty applications.

  • High discharge capacity of 100 to 800 LPM, ideal for farms, industries, and residential use.

  • 100% high-grade copper winding motor for superior efficiency and long service life.

  • Pump body options in Stainless Steel and Cast Iron for corrosion resistance.

  • Energy-efficient, solar-compatible, and suitable for continuous operation.

  • Optional IoT-enabled smart monitoring with mobile app control.

  • Built with world-class technology for dependable, long-lasting performance
SKU: GSE-SPS-V6-AAA1-0101 Categories: , Tags: , , , , , , Brand: , ,

Description

The GlobeSync Enterprise V6 (6-Inch) Submersible Pumpset is a complete, factory-assembled solution that includes a high-performance multi-stage pump and a powerful submersible motor. It is specially designed for deep borewell applications and delivers consistent water flow from depths of 100 to 1500 feet.Manufactured in our advanced production facility using premium raw materials and modern CNC technology, this pumpset ensures high efficiency, excellent durability, and reliable 24/7 performance. It is ideal for agriculture irrigation, industrial water supply, and domestic applications where continuous water availability is critical



GlobeSync V6 Submersible Pumpset – Key Features

  • World-Class Manufacturing: Built using virgin materials and precision CNC-machined components for superior strength and reliability.

  • High Energy Efficiency: Optimized motor-pump matching delivers maximum output with minimal power consumption.

  • Superior Motor Technology: Heavy-duty submersible motor with 100% copper winding, strong thrust bearing, and smooth rotation.

  • User-Friendly Design: Slim and compact body fits easily into narrow borewells with vibration-free and quiet operation.

  • Wide Voltage Range: Performs efficiently under low or fluctuating voltage conditions.

  • Corrosion Protection: SS and coated CI components resist rust and harsh water environments.

  • Powerful Water Flow: Multi-stage impellers provide high pressure and strong discharge.

  • Built-in Safety: Thermal overload protection and non-return valve prevent damage and extend pumpset life.

  • Easy Installation: Maintenance-free design for quick installation and long-term use.

  • Future-Ready: Optional IoT-enabled smart pumpset with mobile monitoring.

  • ISI & BEE Certified: Meets national standards for safety, performance, and energy efficiency.



Common Applications

  • Agricultural irrigation systems

  • Drip and sprinkler irrigation

  • Farm and rural water supply

  • Industrial water handling

  • Deep borewell water extraction

  • Pressure boosting applications

  • Performance may vary based on installation depth, voltage, and water conditions.

  • Images are for representation only; actual product may vary by model.

  • Warranty applies only under recommended operating conditions.

  • Installation must be carried out by a qualified technician.



Technical Specifications

  • Product Type: V6 Borewell Submersible Pumpset (Pump + Motor)

  • Borewell Size: 6 inch (150 mm) and above

  • Material / Body: Stainless Steel (304 / 316 / 202) or Cast Iron

  • Stages: Multi-Stage

  • Discharge Capacity: 100 – 800 LPM

  • Total Head: Up to 450 meters

  • Motor Power Range: 3 HP – 100 HP

  • Voltage: 300V – 440V (Three Phase)

  • Frequency: 50 Hz

  • Cooling: Water Cooled

  • Installation: Vertical (Standard) | Horizontal (Optional)

  • Certification: ISI Certified, BEE Rated

  • Warranty: 12–18 Months (Model Dependent)

Additional information

Weight 100 kg
Dimensions 210 × 6 × 210 cm
Pump–Motor Set

SS Body, Cast Iron Body
Other Information

•Operating Conditions: Suitable for clean or slightly sandy water (up to 50 PPM). Not recommended for highly acidic, chemical-laden, or dirty water sources unless customized.
•Pump & Motor Compatibility: Compatible with 3 HP to 100 HP submersible pumps, BEE-rated or equivalent motors.
•Customization Options: Shaft material, voltage range, motor body, and stage configuration can be tailored for OEM or bulk orders.
•Certifications: Available with ISO, BIS, or CE compliance depending on buyer region or government tender requirements.
•Packaging: Each unit is safely packed in heavy-duty cartons or wooden boxes with proper cushioning to prevent transit damage.
•Installation Recommendation: Must be installed by a qualified technician for optimal performance and to ensure warranty coverage.
•Warranty Coverage: Applies when installed and operated under recommended conditions; damages due to dry running, voltage fluctuations, or misuse are not covered.
